geomembrane

From water containment to chemical containment our wide range of polymers gives us a unique perspective to offer a variety of solutions from PVC, EIA, LLDPE, TPU, and TPO solutions.



Connect with a coated fabric expert >>



E Squared’s line of XTRM Ply® Geomembranes provides the widest range of products for your geomembrane applications. We can produce up to 10’ width allowing factory fabricated panels with less seams than narrow width alternatives. The combination of various polymers, fabrics, and widths provides you with endless design options for your project.

We offer over four decades of experience in matching polymers to applications and can assure you that the products you are buying will meet the demanding needs of your applications.

Proud Member of the following associations:

ATA Advanced Textiles Association
FGI Proud Member

IECA Member





Read relative articles on Geomembrane:

Why Factory-Fabrication is Preferred Over Field-Fabricated Geomembranes

5 Key Factors to Self-Installing Geomembranes for General Contractors

Benefits of Establishing a Line of Communication with a Geomembrane Manufacturer

Considerations for Building a Secondary Containment System

Shear and Peel Strength Testing for your Geomembrane

Geomembrane Wrinkles: Your Challenges and Solutions

geomembrane Applications

  • Canals
  • Ditch Lining
  • Landfill Closures
  • Oil Drilling Reserve Pits
  • Geofoam Wrap
  • Irrigation Ponds
  • Soil Remediation
  • Waste Water Lagoons
  • Mining
  • Long Term Tarps
  • Stock Pile Covers
  • Food Processing
  • Fish Hatcheries
  • Decorative Water Features

geomembrane Products

LLDPE SERIES

NAME
APPLICATION
FABRIC TYPE
COATING
WEIGHT (OZ)
MORE INFO
30011-20120-559 – 20 Mil Black Smooth
Geomembrane
Polyester 1000 Den
LLDPE
20
LLDPE Black – 30 mil
Geomembrane
Polyester 1000 Den
LLDPE
20
LLDPE Reinforced Geomembrane 36mil
Geomembrane
Polyester 1000 Den
LLDPE
24
LLDPE Reinforced Geomembrane 45mil
Geomembrane
Polyester 1000 Den
LLDPE
29
LLDPE Reinforced Geomembrane 60mil
Geomembrane
Polyester 1000 Den
LLDPE
40

Ecoat ® SERIES

NAME
APPLICATION
FABRIC TYPE
COATING
WEIGHT (OZ)
MORE INFO
E 1100 F
Fish Pond Liners, Potable Water Tanks
Polyester 1000 Den
PVC
32.4

ERcoat ® SERIES

NAME
APPLICATION
FABRIC TYPE
COATING
WEIGHT (OZ)
MORE INFO
ER 1365
Berm Liners, Oil Booms, Rescue Boats, Rigid Inflatable Boats, Tanks for Oils
Polyester 1500 Den
EIA/KEE copolymer alloy
40
ER 850
Fertilizer Pools, Liners, Secondary Containment
Polyester 500 Den
EIA/KEE copolymer alloy
25
ER 1000
Berm Liners, Oil Booms, Tanks for cleaning products, Tanks for Oils
Polyester 1000 Den
EIA/KEE copolymer alloy
29.5

REZcoat® SERIES

NAME
APPLICATION
FABRIC TYPE
COATING
WEIGHT (OZ)
MORE INFO
TPU 2037 L
Oil Booms, Rafts, Rigid Inflatable Boats
Polyester 1500 Den
TPU
35.3
TPU 3043
Oil Booms, Rafts, Rescue Boats, Rigid Inflatable Boats
Polyester 1500 Den
TPU
44.3

XTRM Ply® EIA/KEE SERIES

NAME
APPLICATION
FABRIC TYPE
COATING
WEIGHT (OZ)
MORE INFO
7087-30120-559
Primary and Secondary Containment
Polyester 1000 Den
EIA/KEE
30
7087-30120-577
Primary and Secondary Containment
Polyester 1000 Den
EIA/KEE
38
7087-30120-589
EPS Geofoam Protection
Polyester 1000 Den
EIA/KEE
38
