ERcoat™ and XTRM Ply EIA products are a family of E Squared coated fabrics utilizing breakthrough polymer blending to create a uniquely strong EIA/PVC copolymer alloy, which is then applied to a variety of high-quality polyester fabric-based products. The resulting coated fabrics offer excellent resistance to extreme weather conditions, chemicals, abrasion, and punctures, as well as high UV stability. The ERCoat and XTRM Ply EIA are available in mid-range fabric weights and are used primarily in boating, flexible storage tanks, environmental control and other Flexible Geomembrane Liners (FML) applications.

More Information From NSF >>

EPT XTRM PLY EIA andLLDPE, PVC Chemical Resistance Guidelines Aug 2022 >>

E2 XTRM PLY NSF EIA Chemical Resistance Guidelines July 2022 >>

BENEFITS

  • Excellent resistance to extreme weather conditions
  • Excellent chemical resistance
  • High UV stability
  • Abrasion and puncture resistance

Recommended Applications

  • Flexible Storage Tanks
  • Boats
  • Reservoir Liners
  • Floating Covers
  • Waste Baffles
  • Oil & Gas Containment
  • Decorative Ponds & Lakes
  • Landfill Liner & Caps
  • Golf Coure Ponds
  • Pond & Lake Liners
  • Drop-in Tank Liners
  • Greens & Bunker Liners
  • Irrigation Reservoirs
  • Containment Pits
  • Mining Heap Leach Ponds
  • Primary Containment
  • Secondary Containment
  • Potable Water

ERcoat ® SERIES

NAME
APPLICATION
FABRIC TYPE
COATING
WEIGHT (OZ)
MORE INFO
ER 1365
Berm Liners, Oil Booms, Rescue Boats, Rigid Inflatable Boats, Tanks for Oils
Polyester 1500 Den
EIA/KEE
40
ER 850
Fertilizer Pools, Liners, Secondary Containment
Polyester 500 Den
EIA/KEE
25
ER 1000
Berm Liners, Oil Booms, Tanks for cleaning products, Tanks for Oils, Wastewater Baffles
Polyester 1000 Den
EIA/KEE
29.5
7087-30120-559
Primary and Secondary Containment
Polyester 1000 Den
EIA/KEE
30
7087-30120-577
Primary and Secondary Containment
Polyester 1000 Den
EIA/KEE
38
7087-30120-514
Berm Liners, Primary and Secondary Containment
Nylon 1690 Den
EIA/KEE
30
7087-30120-589
EPS Geofoam Protection
Polyester 1000 Den
EIA/KEE
38
